3,600-38,400 lumens, 120 lumens/watt

3G, IP66, 3,000K/4,000K/5,000K, Ra≥70

Lifespan 150,000hrs at 25℃, L80B10

Type I / Type II / Type III / Type IV / Type V optical system

Contact Now

Product Introduction

C0820-QR modular LED street light is massively applied in road lighting field for its excellent performance in luminous efficacy and low light failure. By using the light, power consumption can be reduced by more than 50% compared to traditional light source. The light adopts Sansi ceramic LED technology and unique lens design.


Patented ceramic heat sink technology and air convection design, no PCB, ensuring faster heat dissipation and a longer lifetime.

Unique optical lens design, various optical lenses provide evenly distributed illumination for different road applications.

High-powered LED modules, no wire connection, easy assembly and convenient replacement.

Hollow-structure design ensures good ventilation and reduces wind resistance, makes the luminaires safer and more reliable.

The housing is made of high quality aluminum, anti-corrosion, anti-acid and anti-alkali, durable and long-lasting, IP66.

Tool-free design and self-produced built-in power supply, reducing THD effectively, easy installation and on -site maintenance.

C0820 QR offers all connectivity and dimming options available. Intelligent lighting management system enables you to save on energy and maintenance costs.


What kind of LED products or service do you want ? Where are your projects ? If you are a Brand Distributor, Wholesaler, Retailer, Project Distributor or Developer; or just want to do Brand OEM, please leave us a message, we will have you a more accurate quotation in time.

Technical Parameters

Model Wattage Power Factor Input Voltage CRI Light Efficacy IP Rating Lifespan Temperature
C0820-QR 40W-250W ≥0.95 90-305VAC 70 120lm/W IP66 150,000hrs -40℃-55℃


More of SANSI LED products' applications in its related scenarios, exclusive customizations with customers' specific requirements
